MONOBLOCK ARTICULATED ARM
A system that offers all the advantages of an articulated arm awning, but with a much more robust design. It even allows for the installation of auxiliary arms for greater safety and improved fabric tension.
This type of awning for terraces can cover large areas with a single unit. This is possible because the monoblock awning allows for the placement of multiple additional brackets along the mounting bar. It is a modular type of awning, as joining profiles makes it possible to reach large dimensions.
It is the smallest model, designed to cover small areas using a robust articulated arm system like the monoblock. It can be made with Acrylic or Microperforated fabrics (Soltis or Sunworker). It offers the option of installing a semi-cassette for projections up to 2500 mm, as well as motorization options.
The maximum dimensions it can reach are a 2000 mm projection with a width of up to 5000 mm, and a 2500 mm projection with a width of up to 4000 mm.
Monoblock articulated arm awning model with dimensions of 6000×3500 mm in the 2-arm option. It can be manufactured with Acrylic or Microperforated fabrics (Soltis or Sunworker). It offers the option of installing a semi-cassette and motorization.
A third arm can be added to reach widths of up to 9000 mm, and a fourth arm to reach up to 12000 mm. In these last two cases, the awning can only be made with acrylic fabric.
This is a Monoblock articulated arm awning, mounted on a 40×40 mm square bar made of galvanized and lacquered steel. The arms feature double-sheathed cables, with supports made of extruded aluminum.
The recommended maximum dimensions are 6000 mm in width and 4000 mm in projection, allowing profiles to be joined to achieve greater widths. This type of awning is modular: by connecting multiple profiles, larger widths can be reached.
For installations with three or four arms, this awning can only be manufactured with acrylic fabric.
This Monoblock articulated arm awning model is mounted on a double galvanized steel bar of 60×40 mm, which is lacquered in the color of the awning. The arms feature double stainless steel chains, ensuring maximum durability.
The recommended maximum dimensions are 6000 mm in width and a projection of 5000 mm. It is mounted on a 80 mm rolling axis to ensure proper fabric rolling. This is a modular awning that allows for joining profiles to reach a larger width.
This awning model can only be manufactured with acrylic fabric. It also allows the installation of 2, 3, or 4 arms, up to 12000 mm in width.
